P0300ECRP2
RoHS
/
Package TO-226-2, TO-92-2 (TO-226AC) (Formed Leads)
Category Circuit Protection / TVS - Thyristors
Description
TO-226-2TO-92-2 (TO-226AC) (Formed Leads) SIDACtor? 1 Through Hole TVS Thyristor 40V 100A 250pF 85C
PDF
/
Inventory: 5529
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-2, TO-92-2 (TO-226AC) (Formed Leads)
Surface Mount NO
Technical
Packaging Tape & Reel (TR)
Published 2004
Series SIDACtor?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 250pF
Subcategory Silicon Surge Protectors
Voltage - Rated DC 25V
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code O-PBCY-T2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 100A
Peak Pulse Current 400A
Hold Current 50mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 25V
Non-Repetitive Pk On-state Cur 60 A
Voltage - Breakover 40V
Voltage - On State 4V
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
