P3203ABL60

Littelfuse Inc.
RoHS
RoHS RoHS compliant
Package TO-220-3 No Tab
Category Circuit Protection / TVS - Thyristors
Description SIDAC SYM 3CHP 270V 250A TO220
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.552278
≥1 USD $2.552278
≥200 USD $0.988614
≥500 USD $0.953165
≥1000 USD $0.936098
Inventory: 5551
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Voltage - On State 8V
Voltage - Breakover 350V
Non-Repetitive Pk On-state Cur 25 A
Voltage - Off State 270V
Trigger Device Type SILICON SURGE PROTECTOR
Hold Current 150mA
Peak Pulse Current 250A
Current - Peak Pulse (10/1000μs) 80A
Number of Elements 3
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 10
Current Rating 2.2A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Subcategory Silicon Surge Protectors
Capacitance 45pF 70pF
Additional Feature UL RECOGNIZED
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series SIDACtor?
Published 2011
Packaging Bulk

Physical

Surface Mount NO
Package / Case TO-220-3 No Tab
Mounting Type Through Hole

Supply Chain

Factory Lead Time 21 Weeks
