824541121
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 12V 19.9V DO214AB
PDF
/
Inventory: 9242
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Technical
Number of Bidirectional Channels 1
Max Breakdown Voltage 14V
Bidirectional Channels 1
Breakdown Voltage 14V
Peak Pulse Power 1.5kW
Reverse Standoff Voltage 12V
Peak Pulse Current 75.4A
Voltage - Reverse Standoff (Typ) 12V Max
Clamping Voltage 19.9V
Voltage - Clamping (Max) @ Ipp 19.9V
Current - Peak Pulse (10/1000μs) 75.4A
Power - Peak Pulse 1500W 1.5kW
Voltage - Breakdown (Min) 14V Typ
Power Line Protection No
Polarity Bidirectional
Applications General Purpose
Composition Zener
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series WE-TVSP
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Supplier Device Package DO-214AB
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
