824521850
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 8.5V 14.4V DO214AA
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308
≥1 USD $0.308
≥10 USD $0.2816
≥100 USD $0.25168
Inventory: 529
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Technical
Number of Bidirectional Channels 1
Max Breakdown Voltage 9.92V
Bidirectional Channels 1
Peak Pulse Power 600W
Reverse Standoff Voltage 8.5V
Peak Pulse Current 41.7A
Voltage - Reverse Standoff (Typ) 8.5V Max
Clamping Voltage 14.4V
Voltage - Clamping (Max) @ Ipp 14.4V
Current - Peak Pulse (10/1000μs) 41.7A
Power - Peak Pulse 600W
Voltage - Breakdown (Min) 9.92V Typ
Power Line Protection No
Polarity Bidirectional
Applications General Purpose
Composition Zener
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series WE-TVSP
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Supplier Device Package DO-214AA
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
