SMC5K18AHM3/H
RoHS
/
Package SMC
Category Circuit Protection / TVS - Diodes
Description
PDF
/
Inventory: 1467
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Voltage - Clamping 29.2V
Number of Unidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 5000W
Peak Pulse Power 5kW
Reverse Standoff Voltage 18V
Peak Pulse Current 171.2A
Voltage - Breakdown (Min) 20V
Power Line Protection No
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-J2
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form J BEND
Terminal Position DUAL
Technology AVALANCHE
Additional Feature EXCELLENT CLAMPING CAPABILITY
Composition Zener
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case SMC
Mount Surface Mount
