SM6S17A-E3/2D
RoHS
RoHS compliant
RoHS compliantPackage DO-218AB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 17VWM 27.6VC DO218AB
PDF
/
Inventory: 6103
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Unidirectional Channels 1
Max Breakdown Voltage 20.9V
Breakdown Voltage 18.9V
Unidirectional Channels 1
Test Current 5mA
Direction Unidirectional
Peak Pulse Power 4.6kW
Max Surge Current 600A
Reverse Standoff Voltage 17V
Peak Pulse Current 167A
Voltage - Reverse Standoff (Typ) 17V
Clamping Voltage 27.6V
Voltage - Clamping (Max) @ Ipp 27.6V
Max Reverse Leakage Current 10μA
Current - Peak Pulse (10/1000μs) 167A
Power - Peak Pulse 4600W 4.6kW
Voltage - Breakdown (Min) 18.9V
Power Line Protection No
Power Dissipation 4.6kW
Element Configuration Single
Number of Channels 1
Polarity Unidirectional
Operating Supply Voltage 17V
Base Part Number SM6S
Applications General Purpose
Composition Zener
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Type Zener
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PAR?
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Supplier Device Package DO-218AB
Package / Case DO-218AB
Mounting Type Surface Mount
Mount Surface Mount
