TPD4S012DRYR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 6-UFDFN
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 5.5V 6SON
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.2525
≥1 USD $0.2525
≥10 USD $0.2382
≥100 USD $0.22472
≥500 USD $0.212
≥1000 USD $0.2
≥3000 USD $0.18868
Inventory: 52143
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Thickness 500μm
Width 1mm
Length 1.45mm
Height 600μm

Technical

Ambient Temperature Range High 85°C
Breakdown Voltage 24V
Unidirectional Channels 4
Test Current 1mA
Direction Unidirectional
Peak Pulse Power 60W
Peak Pulse Current 3A
Voltage - Reverse Standoff (Typ) 5.5V
Current - Peak Pulse (10/1000μs) 3A 8/20μs
Voltage - Breakdown (Min) 6V
Power Line Protection Yes
Number of Circuits 4
Configuration COMPLEX
Working Voltage 19V
Number of Elements 2
Operating Supply Voltage 950mV
Pin Count 6
Base Part Number TPD4S012
Depth 1mm
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 60W
Capacitance 15pF
Applications USB
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Steering (Rail to Rail)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA

Physical

Diode Element Material SILICON
Number of Pins 6
Surface Mount YES
Package / Case 6-UFDFN
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
