ESD321DPYR
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1006 Metric)
Category Circuit Protection / TVS - Diodes
Description
HDMI2.0 ESD PROTECTION
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308
≥1 USD $0.308
≥10 USD $0.24024
≥100 USD $0.143968
≥500 USD $0.13332
≥1000 USD $0.090658
≥3000 USD $0.083459
Inventory: 10707
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Non-rep Peak Rev Power Dis-Max 40W
Capacitance @ Frequency 0.9pF @ 1MHz
Rep Pk Reverse Voltage-Max 3.6V
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 3.6V Max
Voltage - Clamping (Max) @ Ipp 6.8V Typ
Current - Peak Pulse (10/1000μs) 6A 8/20μs
Power - Peak Pulse 40W
Voltage - Breakdown (Min) 4.5V
Power Line Protection No
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-N2
Base Part Number ESD321
Terminal Position DUAL
Technology AVALANCHE
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Compliance
RoHS Status ROHS3 Compliant
