SMC30J12A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 12VWM 19.9VC SMC
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.0208
≥1 USD $1.0208
≥10 USD $0.836
≥100 USD $0.65032
≥500 USD $0.551197
≥1000 USD $0.449002
Inventory: 1182
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Number of Unidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 3000W
Breakdown Voltage 13.3V
Direction Unidirectional
Peak Pulse Power 3kW
Reverse Standoff Voltage 12V
Peak Pulse Current 151A
Clamping Voltage 19.9V
Voltage - Clamping (Max) @ Ipp 19.9V
Current - Peak Pulse (10/1000μs) 151A
Power - Peak Pulse 3000W 3kW
Power Line Protection No
Configuration SINGLE
Working Voltage 12V
Number of Elements 1
Pin Count 2
Base Part Number SMC30J
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 3kW
Applications General Purpose
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SMC30J, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
