0437002.WR
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 2A 63VAC/VDC 1206
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2056
≥1 USD $1.2056
≥10 USD $1.16512
≥100 USD $1.08944
≥500 USD $0.901648
≥1000 USD $0.751432
≥3000 USD $0.732618
Inventory: 1216
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 812.8μm
Technical
Pre-arcing Rating 0.225 A2/s
Trip Time or Delay 1 s
Fuse Current 2A
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.058Ohm
Melting I2t 0.144
Breaking Capacity @ Rated Voltage 50A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Power Dissipation 345mW
Physical Dimension 3.2mm x 1.63mm x 0.82mm
Body Breadth 1.63 mm
Case Code (Imperial) 1206
Body Length or Diameter 3.2mm
Approval Agency CSA, UR
Case Code (Metric) 3216
Voltage - Rated AC 63V
Reference Standard CSA; UL
Current Rating 2A
Depth 1.67mm
Packing Method TAPE AND REEL
Voltage - Rated DC 63V
HTS Code 8536.10.00.40
Resistance 58mOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.126Lx0.064W x 0.032 H 3.20mmx1.63mmx0.82mm
Series 437
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C
Physical
Terminal Material Nickel
Body Material Ceramic
Terminal Shape WRAPAROUND
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
