SMBJ10CA-TR
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 10V 21.7V SMB
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.33528
≥100 USD $0.20108
≥500 USD $0.186208
≥1000 USD $0.126614
Inventory: 25453
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 5.59mm
Length 4.6mm
Height 2.45mm
Technical
Max Breakdown Voltage 11.7V
Non-rep Peak Rev Power Dis-Max 4000W
Reverse Breakdown Voltage 11.1V
Breakdown Voltage 11.1V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Max Surge Current 40A
Reverse Standoff Voltage 10V
Peak Pulse Current 184A
Clamping Voltage 21.7V
Voltage - Clamping (Max) @ Ipp 17V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 37A
Power Line Protection No
Power Dissipation 600W
Element Configuration Single
Leakage Current 200nA
Number of Channels 1
Number of Elements 1
Operating Supply Voltage 10V
Pin Count 2
Base Part Number SMBJ
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Voltage - Rated DC 10V
Power Rating 600W
Subcategory Transient Suppressors
Capacitance 2.3nF
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SMBJ, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
