P6KE27A
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
DO-204AC DO-15Axial P6KE TRANSIL? 1 Through Hole Zener Tvs Diode 25.7V 83A 8/20mus 3.53mm 600W
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
≥10 USD $0.44088
≥100 USD $0.306416
≥500 USD $0.239237
Inventory: 11198
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.53mm
Length 6.75mm
Height 3.53mm
Diameter 3.53mm
Technical
Number of Unidirectional Channels 1
Max Breakdown Voltage 28.4V
Reverse Breakdown Voltage 25.7V
Capacitance @ Frequency 1150pF @ 1MHz
Breakdown Voltage 25.7V
Test Current 1mA
Direction Unidirectional
Peak Pulse Power 600W
Max Surge Current 1mA
Reverse Standoff Voltage 23.1V
Peak Pulse Current 83A
Voltage - Reverse Standoff (Typ) 23V
Clamping Voltage 48.3V
Max Reverse Leakage Current 500μA
Current - Peak Pulse (10/1000μs) 83A 8/20μs
Power Line Protection No
Case Connection ISOLATED
Power Dissipation 5W
Element Configuration Single
Leakage Current 500μA
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 23.1V
Pin Count 2
Base Part Number P6KE
Terminal Form WIRE
Technology AVALANCHE
Voltage - Rated DC 27V
Power Rating 600W
Subcategory Transient Suppressors
Capacitance 1.15nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination Through Hole
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series P6KE, TRANSIL?
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
