P6KE220CA
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS Diodes - Transient Voltage Suppressors 600W 220V Bidirect
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.45408
≥100 USD $0.3146
≥500 USD $0.262838
Inventory: 3632
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.53mm
Length 6.75mm
Height 3.53mm
Diameter 3.6 mm
Technical
Max Breakdown Voltage 231V
Reverse Breakdown Voltage 209V
Capacitance @ Frequency 330pF @ 1MHz
Breakdown Voltage 209V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Max Surge Current 1mA
Reverse Standoff Voltage 188V
Peak Pulse Current 10.3A
Clamping Voltage 388V
Max Reverse Leakage Current 500μA
Current - Peak Pulse (10/1000μs) 10.3A 8/20μs
Power Line Protection No
Case Connection ISOLATED
Element Configuration Single
Power Dissipation-Max 5W
Leakage Current 500μA
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 188V
Pin Count 2
Base Part Number P6KE
Terminal Form WIRE
Technology AVALANCHE
Subcategory Transient Suppressors
Capacitance 330pF
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series P6KE, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
