LNBTVS3-220U
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 20VWM 35VC SMB
PDF
/
Inventory: 1569
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.95mm
Length 4.6mm
Technical
Number of Unidirectional Channels 1
Max Breakdown Voltage 24.2V
Breakdown Voltage 22V
Test Current 1mA
Peak Pulse Power 22.5kW
Max Surge Current 250A
Reverse Standoff Voltage 20V
Peak Pulse Current 250A
Clamping Voltage 35V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 250A 8/20μs
Power - Peak Pulse 22500 22.5kW
Power Line Protection No
Power Dissipation 5W
Element Configuration Single
Leakage Current 200nA
Polarity Unidirectional
Working Voltage 20V
Number of Elements 1
Operating Supply Voltage 20V
Pin Count 2
Base Part Number LNBTVS
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 5W
Voltage - Rated DC 22V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 3nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series LNBTVS, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
