LDP24ARL
RoHS
RoHS compliant
RoHS compliantPackage R6, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 24V 40V R-6
PDF
/
Buying Options
Total Price: USD $2.36
Unit Price: USD $2.3584
≥1 USD $2.3584
≥10 USD $1.98088
≥100 USD $1.602744
≥500 USD $1.424632
Inventory: 847
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case R6, Axial
Number of Pins 6
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series LDP
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Capacitance 8nF
Max Power Dissipation 5W
Technology AVALANCHE
Terminal Form WIRE
Base Part Number LDP24
Pin Count 2
JESD-30 Code O-PALF-W2
Operating Supply Voltage 24V
Number of Elements 1
Working Voltage 24V
Polarity UNIDIRECTIONAL
Leakage Current 50μA
Element Configuration Single
Case Connection ISOLATED
Power Line Protection No
Current - Peak Pulse (10/1000μs) 30A 8/20μs
Max Reverse Leakage Current 50μA
Clamping Voltage 40V
Peak Pulse Current 30A
Reverse Standoff Voltage 24V
Max Surge Current 50μA
Peak Pulse Power 5W
Test Current 1mA
Breakdown Voltage 25V
Capacitance @ Frequency 8000pF @ 1MHz
Reverse Breakdown Voltage 25V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
