ESDAVLC5-1BF4
RoHS
RoHS compliant
RoHS compliantPackage 0201 (0603 Metric)
Category Circuit Protection / TVS - Diodes
Description
STMICROELECTRONICS ESDAVLC5-1BF4 TVS Diode, ESDAV Series, Bidirectional, 5.3 V, 11.7 V, 0201, 2 Pins
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.15136
≥100 USD $0.07392
≥500 USD $0.061653
≥1000 USD $0.042838
≥3000 USD $0.037127
Inventory: 132522
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Breakdown Voltage 8.5V
Capacitance @ Frequency 7pF @ 1MHz
Bidirectional Channels 1
Breakdown Voltage 5.8V
Peak Pulse Power 20W
Reverse Standoff Voltage 5.3V
Peak Pulse Current 1.7A
Voltage - Reverse Standoff (Typ) 5.3V Max
Clamping Voltage 19.2V
Voltage - Clamping (Max) @ Ipp 19.2V Typ
Current - Peak Pulse (10/1000μs) 1.7A 8/20μA
Power Line Protection No
Polarity Bidirectional
Case Code (Imperial) 0201
Case Code (Metric) 0603
Base Part Number ESDAVLC5
Applications General Purpose
Type Zener
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Cut Tape (CT)
Operating Temperature -55°C~150°C TJ
Physical
Number of Pins 2
Package / Case 0201 (0603 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 15 Weeks
