2206.750HXP
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm (Axial)
Category Circuit Protection / Fuses
Description
FUSE GLASS 750MA 300VAC 2AG
PDF
/
Buying Options
Total Price: USD $1.46
Unit Price: USD $1.459945
≥1 USD $1.459945
≥200 USD $0.56586
≥500 USD $0.546166
≥1000 USD $0.535663
Inventory: 6854
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Fuse Class Supplemental
Trip Time or Delay 14400 s
Fuse Size 2AG
Circuit Protection Type Electric Fuse
DC Cold Resistance 0.152Ohm
Melting I2t 1.05
Breaking Capacity @ Rated Voltage 100A
Fuse Type Cartridge, Glass
Response Time Fast Blow
Body Length or Diameter 14.48mm
Approval Agency CE, CSA, UL
Voltage - Rated AC 300V
Reference Standard CSA; UL
Current Rating 750mA
Reach Compliance Code unknown
Terminal Finish Tin (Sn)
Resistance 152mOhm
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.185Diax0.570L 4.70mmx14.48mm
Series 2206
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Terminal Shape PIN WIRE
Package / Case 2AG, 5mm x 15mm (Axial)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
