ESDA6V1-5M6
RoHS
RoHS compliant
RoHS compliantPackage 6-UFDFN
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 3VWM 6QFN
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.29392
≥100 USD $0.176352
≥500 USD $0.16331
≥1000 USD $0.111056
Inventory: 1242
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 1mm
Length 1.45mm
Height 550μm
Technical
ESD Protection Yes
Max Breakdown Voltage 7.2V
Reverse Breakdown Voltage 6.1V
Capacitance @ Frequency 70pF @ 1MHz
Breakdown Voltage 6.1V
Test Current 1mA
Peak Pulse Power 100W
Max Surge Current 8A
Reverse Standoff Voltage 3V
Peak Pulse Current 8A
Clamping Voltage 3V
Max Reverse Leakage Current 500nA
Power Line Protection No
Element Configuration Common Anode
Leakage Current 500nA
Polarity Unidirectional
Number of Elements 5
Operating Supply Voltage 1V
Pin Count 6
Base Part Number ESDA6
Time@Peak Reflow Temperature-Max (s) 30
Depth 1mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 100W
Voltage - Rated DC 6.1V
Power Rating 100W
Subcategory Transient Suppressors
Capacitance 70pF
Applications General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series ESDA, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Diode Element Material SILICON
Number of Pins 6
Package / Case 6-UFDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 11 Weeks
