MXL1.5KE20A
RoHS
/
Package DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
Diode TVS Single Uni-Dir 17.1V 1.5KW 2-Pin Case 1
PDF
/
Inventory: 6284
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Unidirectional Channels 1
Test Current 1mA
Direction Unidirectional
Peak Pulse Power 1.5kW
Reverse Standoff Voltage 17.1V
Peak Pulse Current 54A
Clamping Voltage 27.7V
Max Reverse Leakage Current 1μA
Power - Peak Pulse 1500W 1.5kW
Voltage - Breakdown (Min) 19V
Power Line Protection No
Case Connection ISOLATED
Element Configuration Single
Number of Elements 1
Pin Count 2
Terminal Form WIRE
Technology AVALANCHE
Additional Feature HIGH RELIABILITY
Applications General Purpose
Terminal Finish TIN LEAD
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Series Military, MIL-PRF-19500
Packaging Bulk
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-201AA, DO-27, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
