UPT28/TR13 image
Favorite
UPT28/TR13 image
Favorite
RoHS
/
Package DO-216AA
Category Circuit Protection / TVS - Diodes
Description ESD Suppressor TVS 2-Pin(1+Tab) Power Mite T/R
PDF
/
Inventory: 2767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Unidirectional Channels 1
Direction Unidirectional
Clamping Voltage 47.8V
Current - Peak Pulse (10/1000μs) 3.13A
Power - Peak Pulse 1000W 1kW
Voltage - Breakdown (Min) 31V
Power Line Protection No
Configuration SINGLE
Working Voltage 28V
Number of Elements 1
Pin Count 2
Base Part Number UPT28
Terminal Form GULL WING
Terminal Position DUAL
Technology AVALANCHE
Applications General Purpose
Terminal Finish MATTE TIN
Type Zener
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case DO-216AA
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
