SMAJ170A-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 170V 275V DO214AC
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3432
≥1 USD $0.3432
≥10 USD $0.24552
≥100 USD $0.123728
≥500 USD $0.109648
≥1000 USD $0.085325
≥3000 USD $0.076366
Inventory: 4627
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Clamping Voltage-Max 275V
Non-rep Peak Rev Power Dis-Max 400W
Breakdown Voltage 199V
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 170V
Voltage - Clamping (Max) @ Ipp 275V
Current - Peak Pulse (10/1000μs) 1.5A
Power - Peak Pulse 400W
Voltage - Breakdown (Min) 189V
Power Line Protection No
Power Dissipation-Max 1W
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PDSO-C2
Pin Count 2
Base Part Number SMAJ
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TA
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
