1.5KE20A-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-201AE, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 17.1V 27.7V DO201AE
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.38896
≥100 USD $0.270336
≥500 USD $0.211094
Inventory: 1274
Minimum: 1
-
+
Technical Details
Technical
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature CMOS COMPATIBLE, UL RECOGNIZED
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Form WIRE
Base Part Number 1.5KE
Pin Count 2
JESD-30 Code O-PALF-W2
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Power Dissipation-Max 5W
Case Connection ISOLATED
Power Line Protection No
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Clamping Voltage-Max 27.7V
Breakdown Voltage 20V
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 17.1V
Voltage - Clamping (Max) @ Ipp 27.7V
Power - Peak Pulse 1500W 1.5kW
Voltage - Breakdown (Min) 19V
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case DO-201AE, Axial
Mounting Type Through Hole
Supply Chain
Factory Lead Time 12 Weeks
Compliance
RoHS Status ROHS3 Compliant
