SMA6L43A
RoHS
RoHS compliant
RoHS compliantPackage DO-221AC, SMA Flat Leads
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 43VWM 69.4VC DO221AC
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.31064
≥100 USD $0.216128
≥500 USD $0.168731
≥1000 USD $0.137148
Inventory: 1077
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-221AC, SMA Flat Leads
Diode Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2014
Series SMA6L
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature EXCELLENT CLAMPING CAPABILITY
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
JESD-30 Code R-PDSO-F2
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Power Dissipation-Max 3W
Power Line Protection No
Voltage - Breakdown (Min) 47.8V
Current - Peak Pulse (10/1000μs) 8.7A
Clamping Voltage 69.4V
Voltage - Reverse Standoff (Typ) 43V
Peak Pulse Current 8.7A
Reverse Standoff Voltage 43V
Peak Pulse Power 600W
Unidirectional Channels 1
Breakdown Voltage 50.3V
Compliance
RoHS Status ROHS3 Compliant
