20KPA72
RoHS
RoHS compliant
RoHS compliantPackage P600, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 72VWM 121.8VC AXIAL
PDF
/
Inventory: 4608
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of Unidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 20000W
Breakdown Voltage 80.4V
Peak Pulse Power 20kW
Max Surge Current 174.1A
Reverse Standoff Voltage 72V
Peak Pulse Current 174.1A
Clamping Voltage 121.8V
Power - Peak Pulse 20000W 20kW
Voltage - Breakdown (Min) 75.98V
Power Line Protection No
Case Connection ISOLATED
Power Dissipation-Max 8W
Configuration SINGLE
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 72V
JESD-30 Code O-PALF-W2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form WIRE
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Termination Axial
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series 20KPA
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Package / Case P600, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
