TZB4Z030EB10R01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Capacitors / Trimmers, Variable Capacitors
Description
TZB4 VARIABLE CAPACITOR Trimmer Capacitor 0.177Lx0.157W 4.50mmx4.00mm 1.4pF~3pF 100V
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.04113
≥1 USD $1.04113
≥200 USD $0.416189
≥500 USD $0.401747
≥1000 USD $0.395183
Inventory: 4161
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 7mm
Height Seated (Max) 0.126 3.20mm
Technical
Adjuster Orientation VERTICAL
Capacitance Range 1.4pF~3pF
Adjustment Type Bottom Adjustment
Q @ Freq 300 @ 1MHz
Positive Tolerance 50%
Size Code 2816
Rated (DC) Voltage (URdc) 100V
Capacitor Type VARIABLE CAPACITOR
Packing Method TR, 13 INCH
HTS Code 8532.30.00.10
Additional Feature PERCENTAGE TOLERANCE ON C_MAX IS 0/+50
Voltage - Rated 100V
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature General Purpose
JESD-609 Code e3
Size / Dimension 0.177Lx0.157W 4.50mmx4.00mm
Series TZB4
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Dielectric Material Ceramic
Terminal Shape GULL WING
Surface Mount YES
Mounting Type Surface Mount
