89PR50LF image
Favorite
89PR50LF image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Potentiometers, Variable Resistors / Trimmer Potentiometers
Description Cermet TRIMMER HORIZONTAL SCREW Trimmer Potentiometer ±20% 0.75W 3/4W 85C 50Ohm
PDF
/
Inventory: 4181
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mounting Type Through Hole
Surface Mount NO
Terminal Shape WIRE
Resistive Material Cermet

Technical

Published 2006
Series 89
Size / Dimension Rectangular - 0.810 x 0.190 Face x 0.250 H 20.57mmx4.83mmx6.35mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Number of Terminations 3
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 50Ohm
Terminal Finish Matte Tin (Sn)
Power (Watts) 0.75W 3/4W
HTS Code 8533.40.80.50
Subcategory Variable Resistors
Packing Method BULK
Construction Trimmer Pot
Resistor Type TRIMMER
Termination Style PC Pins
Rated Power Dissipation (P) 0.75W
Operating Temperature (Max) 125°C
Actuator Type SCREW
Operating Temperature (Min) -55°C
Lead Length 4.445mm
Lead Diameter 0.533 mm
Size Code 7519
Rated Temperature 85°C
Adjustment Type Side Adjustment
Number of Turns 20
Actuator Orientation HORIZONTAL

Compliance

RoHS Status RoHS Compliant
