DSK9J01P0L
RoHS
RoHS compliant
RoHS compliantPackage SC-89, SOT-490
Category Discrete Semiconductor Products / Transistors - JFETs
Description
JFET N-CH 30MA 125MW SSMINI3
PDF
/
Inventory: 4792
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 850μm
Length 1.6mm
Height 700μm
Technical
Voltage - Cutoff (VGS off) @ Id 5V @ 10μA
Current - Drain (Idss) @ Vds (Vgs=0) 1mA @ 10V
FET Technology JUNCTION
Gate to Source Voltage (Vgs) -55V
Continuous Drain Current (ID) 30mA
Drain to Source Voltage (Vdss) 55V
Input Capacitance (Ciss) (Max) @ Vds 6pF @ 10V
Transistor Application AMPLIFIER
FET Type N-Channel
Operating Mode DEPLETION MODE
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number DSK9J01
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Terminal Position DUAL
Max Power Dissipation 125mW
HTS Code 8541.21.00.95
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Published 2010
Packaging Cut Tape (CT)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case SC-89, SOT-490
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
