MMBF4093
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - JFETs
Description
Trans JFET N-CH 3-Pin SOT-23 T/R
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.44
≥1 USD $0.44
≥10 USD $0.34232
≥100 USD $0.205216
≥500 USD $0.189974
≥1000 USD $0.129184
Inventory: 3944
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.3mm
Length 2.92mm
Height 930μm
Technical
Resistance - RDS(On) 80Ohm
Voltage - Cutoff (VGS off) @ Id 1V @ 1nA
Current - Drain (Idss) @ Vds (Vgs=0) 8mA @ 20V
Feedback Cap-Max (Crss) 5 pF
Drain to Source Resistance 80Ohm
FET Technology JUNCTION
Gate to Source Voltage (Vgs) -40V
Continuous Drain Current (ID) 8mA
Drain to Source Voltage (Vdss) 40V
Input Capacitance (Ciss) (Max) @ Vds 16pF @ 20V
Transistor Application SWITCHING
FET Type N-Channel
Power Dissipation 350mW
Operating Mode DEPLETION MODE
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Base Part Number MBF4093
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 50mA
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 350mW
Voltage - Rated DC 40V
Subcategory Other Transistors
HTS Code 8541.21.00.95
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2000
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 30mg
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
