STGWA20M65DF2

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description IGBT TRENCH 650V 40A TO247
PDF
/
Buying Options
Total Price: USD $901.8
Unit Price: USD $1.503008
≥600 USD $1.503008
Inventory: 1512
Minimum: 600
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Switching Energy 140μJ (on), 560μJ (off)
Td (on/off) @ 25°C 26ns/108ns
Current - Collector Pulsed (Icm) 80A
Gate Charge 63nC
IGBT Type Trench Field Stop
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 20A
Test Condition 400V, 20A, 12 Ω, 15V
Current - Collector (Ic) (Max) 40A
Voltage - Collector Emitter Breakdown (Max) 650V
Reverse Recovery Time 166ns
Power - Max 166W
Input Type Standard
Base Part Number STGWA20
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series M
Operating Temperature -55°C~175°C TJ

Physical

Package / Case TO-247-3
Mounting Type Through Hole

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 30 Weeks
