NGD8205NT4G
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tape & Reel (TR) Surface Mount ROHS3Compliant IGBT Transistor 1.9V @ 4.5V 20A 20A 125W -/5mus
PDF
/
Buying Options
Total Price: USD $8.38
Unit Price: USD $8.37995
≥1 USD $8.37995
≥10 USD $6.8761
≥100 USD $6.6614
≥500 USD $6.4467
≥1000 USD $6.232
Inventory: 21307
Minimum: 1
-
+
Technical Details
Technical
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Input Type Logic
Power - Max 125W
Voltage - Collector Emitter Breakdown (Max) 390V
Current - Collector (Ic) (Max) 20A
Test Condition 300V, 9A, 1kOhm, 5V
Vce(on) (Max) @ Vge, Ic 1.9V @ 4.5V, 20A
Current - Collector Pulsed (Icm) 50A
Td (on/off) @ 25°C -/5μs
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Compliance
RoHS Status ROHS3 Compliant
Physical
Supplier Device Package DPAK
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
