IRGR3B60KD2TRLP
RoHS
/
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tape & Reel (TR) Surface Mount NPT Non-RoHS Compliant IGBT Transistor 2.4V @ 15V 3A 7.8A 52W 77ns
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 1307
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package D-Pak
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Input Type Standard
Power - Max 52W
Reverse Recovery Time 77ns
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 7.8A
Test Condition 400V, 3A, 100Ohm, 15V
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 3A
IGBT Type NPT
Gate Charge 13nC
Current - Collector Pulsed (Icm) 15.6A
Td (on/off) @ 25°C 18ns/110ns
Switching Energy 62μJ (on), 39μJ (off)
Compliance
RoHS Status Non-RoHS Compliant
