IRGP6630D-EPBF image
Favorite
IRGP6630D-EPBF image
Favorite
RoHS
RoHS RoHS compliant
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description Tube Through Hole ROHS3Compliant IGBT Transistor 1.95V @ 15V 18A 47A 192W 70ns
PDF
/
Inventory: 5814
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Switching Energy 75μJ (on), 350μJ (off)
Td (on/off) @ 25°C 40ns/95ns
Current - Collector Pulsed (Icm) 54A
Gate Charge 30nC
Vce(on) (Max) @ Vge, Ic 1.95V @ 15V, 18A
Test Condition 400V, 18A, 22Ohm, 15V
Current - Collector (Ic) (Max) 47A
Voltage - Collector Emitter Breakdown (Max) 600V
Reverse Recovery Time 70ns
Power - Max 192W
Input Type Standard
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature -40°C~175°C TJ

Physical

Supplier Device Package TO-247AD
Package / Case TO-247-3
Mounting Type Through Hole
