IRGB4061DPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Through Hole Trench ROHS3Compliant IGBT Transistor 1.95V @ 15V 18A 36A 206W 100ns
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 11304
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220AB
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Input Type Standard
Power - Max 206W
Reverse Recovery Time 100ns
Voltage - Collector Emitter Breakdown (Max) 600V
Current - Collector (Ic) (Max) 36A
Test Condition 400V, 18A, 22Ohm, 15V
Vce(on) (Max) @ Vge, Ic 1.95V @ 15V, 18A
IGBT Type Trench
Gate Charge 35nC
Current - Collector Pulsed (Icm) 72A
Td (on/off) @ 25°C 40ns/105ns
Switching Energy 95μJ (on), 350μJ (off)
Compliance
RoHS Status ROHS3 Compliant
