IRG4IBC20UDPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Through Hole ROHS3Compliant IGBT Transistor 2.1V @ 15V 6.5A 11.4A 34W 37ns
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.8536
≥1 USD $0.8536
Inventory: 268123
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Energy 160μJ (on), 130μJ (off)
Td (on/off) @ 25°C 39ns/93ns
Current - Collector Pulsed (Icm) 52A
Gate Charge 27nC
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 6.5A
Test Condition 480V, 6.5A, 50Ohm, 15V
Current - Collector (Ic) (Max) 11.4A
Voltage - Collector Emitter Breakdown (Max) 600V
Reverse Recovery Time 37ns
Power - Max 34W
Input Type Standard
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Supplier Device Package TO-220AB Full-Pak
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
