FGPF50N30TTU
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Through Hole Trench SINGLE IGBT Transistor 1.5V @ 15V 15A 120A 46.8W 423ns
PDF
/
Buying Options
Total Price: USD $1.27
Unit Price: USD $1.2672
≥1 USD $1.2672
Inventory: 888
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 3
Terminal Finish MATTE TIN
Additional Feature LOW CONDUCTION LOSS
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Case Connection ISOLATED
Input Type Standard
Power - Max 46.8W
Transistor Application MOTOR CONTROL
Polarity/Channel Type N-CHANNEL
JEDEC-95 Code TO-220AB
Voltage - Collector Emitter Breakdown (Max) 300V
Turn On Time 108 ns
Vce(on) (Max) @ Vge, Ic 1.5V @ 15V, 15A
Turn Off Time-Nom (toff) 423 ns
IGBT Type Trench
Gate Charge 97nC
Current - Collector Pulsed (Icm) 120A
Compliance
RoHS Status ROHS3 Compliant
