FGPF45N45TTU
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Through Hole Trench SINGLE IGBT Transistor 1.5V @ 15V 20A 180A 51.6W 412ns
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.0208
≥1 USD $1.0208
Inventory: 5443
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Collector Pulsed (Icm) 180A
Gate Charge 100nC
IGBT Type Trench
Turn Off Time-Nom (toff) 412 ns
Vce(on) (Max) @ Vge, Ic 1.5V @ 15V, 20A
Turn On Time 112 ns
Voltage - Collector Emitter Breakdown (Max) 450V
JEDEC-95 Code TO-220AB
Polarity/Channel Type N-CHANNEL
Transistor Application MOTOR CONTROL
Power - Max 51.6W
Input Type Standard
Case Connection ISOLATED
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSFM-T3
Pin Count 3
Terminal Position SINGLE
Additional Feature LOW CONDUCTION LOSS
Number of Terminations 3
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
