IXYH20N65C3D1
RoHS
/
Package TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
DISC IGBT XPT-GENX4 TO-247AD
PDF
/
Buying Options
Total Price: USD $13.72
Unit Price: USD $13.722431
≥1 USD $13.722431
≥200 USD $5.310681
≥500 USD $5.124249
≥1000 USD $5.032346
Inventory: 3825
Minimum: 1
-
+
Technical Details
Technical
Switching Energy 430μJ (on), 350μJ (off)
Td (on/off) @ 25°C 19ns/80ns
Current - Collector Pulsed (Icm) 105A
Gate Charge 30nC
IGBT Type PT
Vce(on) (Max) @ Vge, Ic 2.5V @ 15V, 20A
Test Condition 400V, 20A, 20 Ω, 15V
Current - Collector (Ic) (Max) 50A
Voltage - Collector Emitter Breakdown (Max) 650V
Reverse Recovery Time 34ns
Power - Max 230W
Input Type Standard
Part Status Active
Series XPT?, GenX3?
Operating Temperature -55°C~175°C TJ
Physical
Package / Case TO-247-3
Mounting Type Through Hole
Supply Chain
Factory Lead Time 28 Weeks
