FD400R33KF2C
RoHS
/
Package Module
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT Modules 3300V 400A CHOPPER
PDF
/
Inventory: 7333
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Technical
VCEsat-Max 4.25 V
Gate-Emitter Voltage-Max 20V
Turn Off Time-Nom (toff) 1900 ns
Collector Current-Max (IC) 660A
Turn On Time 480 ns
Collector Emitter Saturation Voltage 3.4V
Collector Emitter Voltage (VCEO) 330V
Polarity/Channel Type N-CHANNEL
Halogen Free Not Halogen Free
Transistor Application POWER CONTROL
Case Connection ISOLATED
Power Dissipation 4.8kW
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-XUFM-X5
Pin Count 7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Insulated Gate BIP Transistors
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 5
Part Status Active
Pbfree Code no
Published 2002
Physical
Surface Mount NO
Package / Case Module
