IXGQ28N120BD1
RoHS
RoHS compliant
RoHS compliantPackage TO-3P-3, SC-65-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
Tube Through Hole N-CHANNEL Single IGBT Transistor 3.5V @ 15V 28A 150A 250W 40ns
PDF
/
Inventory: 1934
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-3P-3, SC-65-3
Number of Pins 3
Weight 5.500006g
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2004
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 250W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number IXG*28N120
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Case Connection COLLECTOR
Input Type Standard
Power - Max 250W
Transistor Application POWER CONTROL
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 1.2kV
Max Collector Current 50A
Reverse Recovery Time 40 ns
Collector Emitter Breakdown Voltage 1.2kV
Voltage - Collector Emitter Breakdown (Max) 1200V
Turn On Time 63 ns
Test Condition 960V, 28A, 5 Ω, 15V
Vce(on) (Max) @ Vge, Ic 3.5V @ 15V, 28A
Turn Off Time-Nom (toff) 550 ns
Gate Charge 92nC
Current - Collector Pulsed (Icm) 150A
Td (on/off) @ 25°C 30ns/180ns
Switching Energy 2mJ (off)
Compliance
RoHS Status ROHS3 Compliant
