IXGH10N100
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - IGBTs - Single
Description
IGBT 1000V 20A 100W TO247AD
PDF
/
Inventory: 9782
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Turn On Time 300 ns
Vce(on) (Max) @ Vge, Ic 3.5V @ 15V, 10A
Turn Off Time-Nom (toff) 1850 ns
Gate-Emitter Voltage-Max 20V
Gate-Emitter Thr Voltage-Max 5V
Voltage - Collector Emitter Breakdown (Max) 1000V
Collector Emitter Breakdown Voltage 1kV
JEDEC-95 Code TO-247AD
Max Collector Current 20A
Collector Emitter Voltage (VCEO) 3.5V
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 100W
Input Type Standard
Case Connection COLLECTOR
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Base Part Number IXG*10N100
Terminal Position SINGLE
Max Power Dissipation 100W
Subcategory Insulated Gate BIP Transistors
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Tube
Compliance
RoHS Status ROHS3 Compliant
Physical
Transistor Element Material SILICON
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
Alternative Model
