APTGT300DA170G
RoHS
RoHS compliant
RoHS compliantPackage SP6
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MODULE 1700V 400A 1660W SP6
PDF
/
Buying Options
Total Price: USD $648.23
Unit Price: USD $648.232559
≥1 USD $648.232559
≥200 USD $258.649177
≥500 USD $250.006357
≥1000 USD $245.735493
Inventory: 8690
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Input Capacitance (Cies) @ Vce 26.5nF @ 25V
NTC Thermistor No
IGBT Type Trench Field Stop
Turn Off Time-Nom (toff) 1100 ns
Vce(on) (Max) @ Vge, Ic 2.4V @ 15V, 300A
Turn On Time 450 ns
Input Capacitance 26.5nF
Voltage - Collector Emitter Breakdown (Max) 1700V
Collector Emitter Breakdown Voltage 1.7kV
Current - Collector Cutoff (Max) 750μA
Max Collector Current 400A
Collector Emitter Voltage (VCEO) 1.7kV
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 1660W
Case Connection ISOLATED
Configuration Single
Number of Elements 1
Pin Count 5
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 1.66kW
Additional Feature AVALANCHE RATED
Terminal Finish TIN SILVER COPPER
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2012
Operating Temperature -40°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 5
Package / Case SP6
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 36 Weeks
Alternative Model
