BSM50GB60DLC
RoHS
/
Package /
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT Modules 600V 50A DUAL
PDF
/
Buying Options
Total Price: USD $113.45
Unit Price: USD $113.454254
≥1 USD $113.454254
≥200 USD $43.906002
≥500 USD $42.362031
≥1000 USD $41.600549
Inventory: 6412
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
VCEsat-Max 2.45 V
Gate-Emitter Voltage-Max 20V
Collector-Emitter Voltage-Max 600V
Turn Off Time-Nom (toff) 151 ns
Collector Current-Max (IC) 75A
Turn On Time 52 ns
Power Dissipation-Max (Abs) 280W
Polarity/Channel Type N-CHANNEL
Case Connection ISOLATED
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODE
Number of Elements 2
Operating Temperature (Max) 175°C
Qualification Status Not Qualified
JESD-30 Code R-XUFM-X7
Pin Count 7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Insulated Gate BIP Transistors
ECCN Code EAR99
Pbfree Code icon-pbfree no
Physical
Transistor Element Material SILICON
Number of Terminals 7
Surface Mount NO
