MIXA100W1200TEH
RoHS
RoHS compliant
RoHS compliantPackage E3
Category Discrete Semiconductor Products / Transistors - IGBTs - Modules
Description
IGBT MODULE 1200V 155A 500W E3
PDF
/
Buying Options
Total Price: USD $354.79
Unit Price: USD $354.788906
≥1 USD $354.788906
≥200 USD $141.563443
≥500 USD $136.833064
≥1000 USD $134.496102
Inventory: 6849
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Gate-Emitter Voltage-Max 20V
NTC Thermistor Yes
IGBT Type PT
Turn Off Time-Nom (toff) 350 ns
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 100A
Turn On Time 110 ns
Voltage - Collector Emitter Breakdown (Max) 1200V
Collector Emitter Breakdown Voltage 1.2kV
Current - Collector Cutoff (Max) 300μA
Max Collector Current 155A
Collector Emitter Voltage (VCEO) 2.1V
Input Standard
Polarity/Channel Type N-CHANNEL
Transistor Application POWER CONTROL
Power - Max 500W
Case Connection ISOLATED
Configuration Three Phase Inverter
Number of Elements 6
JESD-30 Code R-XUFM-X35
Terminal Form UNSPECIFIED
Terminal Position UPPER
Max Power Dissipation 500W
Subcategory Insulated Gate BIP Transistors
Additional Feature UL RECOGNIZED
Number of Terminations 35
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2011
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Transistor Element Material SILICON
Package / Case E3
Mounting Type Chassis Mount
Mount Chassis Mount
