CSD17577Q5AT
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerTDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
TEXAS INSTRUMENTS CSD17577Q5ATMOSFET Transistor, N Channel, 60 A, 30 V, 0.0035 ohm, 10 V, 1.4 V
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8976
≥1 USD $0.8976
≥10 USD $0.73216
≥100 USD $0.569448
Inventory: 2902
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1mm
Width 6mm
Length 4.9mm
Technical
Avalanche Energy Rating (Eas) 39 mJ
DS Breakdown Voltage-Min 30V
Drain-source On Resistance-Max 0.0042Ohm
Drain Current-Max (Abs) (ID) 22A
Gate to Source Voltage (Vgs) 20V
Threshold Voltage 1.4V
Continuous Drain Current (ID) 60A
Turn-Off Delay Time 18 ns
Fall Time (Typ) 2 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 30V
Rise Time 12ns
Gate Charge (Qg) (Max) @ Vgs 35nC @ 10V
Current - Continuous Drain (Id) @ 25°C 60A Ta
Input Capacitance (Ciss) (Max) @ Vds 2310pF @ 15V
Vgs(th) (Max) @ Id 1.8V @ 250μA
Rds On (Max) @ Id, Vgs 4.2m Ω @ 18A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 3 ns
Case Connection DRAIN
Power Dissipation 3W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 3W Ta 53W Tc
Number of Channels 1
Number of Elements 1
Base Part Number CSD17577
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Additional Feature AVALANCHE RATED
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series NexFET?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 8
Package / Case 8-PowerTDFN
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
