RS1E320GNTB
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerTDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 30V 32A 8-HSOP
PDF
/
Inventory: 5928
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-PowerTDFN
Number of Pins 8
Weight 70.590313mg
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2015
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Technology MOSFET (Metal Oxide)
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-F5
Number of Elements 1
Number of Channels 1
Power Dissipation-Max 3W Ta 34.6W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Case Connection DRAIN
Turn On Delay Time 21.8 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 1.9m Ω @ 32A, 10V
Vgs(th) (Max) @ Id 2.5V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds 2850pF @ 15V
Current - Continuous Drain (Id) @ 25°C 32A Ta
Gate Charge (Qg) (Max) @ Vgs 42.8nC @ 10V
Rise Time 15.6ns
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Vgs (Max) ±20V
Fall Time (Typ) 28.5 ns
Turn-Off Delay Time 74.6 ns
Continuous Drain Current (ID) 32A
Gate to Source Voltage (Vgs) 20V
Drain-source On Resistance-Max 0.0024Ohm
Drain to Source Breakdown Voltage 30V
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
