CSD16409Q3
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerTDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
N CHANNEL MOSFET, 25V, 60A, SON
PDF
/
Buying Options
Total Price: USD $0.82
Unit Price: USD $0.8184
≥1 USD $0.8184
≥10 USD $0.66968
≥100 USD $0.520784
≥500 USD $0.44139
≥1000 USD $0.359568
Inventory: 1136
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-PowerTDFN
Number of Pins 8
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series NexFET?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Termination SMD/SMT
ECCN Code EAR99
Additional Feature AVALANCHE RATED
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Base Part Number CSD16409
Pin Count 8
Number of Elements 1
Power Dissipation-Max 2.6W Ta
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 2.6W
Case Connection DRAIN
Turn On Delay Time 6.5 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 8.2m Ω @ 17A, 10V
Vgs(th) (Max) @ Id 2.3V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 800pF @ 12.5V
Current - Continuous Drain (Id) @ 25°C 15A Ta 60A Tc
Gate Charge (Qg) (Max) @ Vgs 5.6nC @ 4.5V
Rise Time 10.6 ns
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Vgs (Max) +16V, -12V
Fall Time (Typ) 3.4 ns
Turn-Off Delay Time 6.3 ns
Continuous Drain Current (ID) 60A
Threshold Voltage 2V
Gate to Source Voltage (Vgs) 16V
Drain to Source Breakdown Voltage 25V
Pulsed Drain Current-Max (IDM) 90A
Dual Supply Voltage 25V
Avalanche Energy Rating (Eas) 72 mJ
Nominal Vgs 2 V
Feedback Cap-Max (Crss) 55 pF
Dimensions
Height 1.1mm
Length 3.3mm
Width 3.3mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
