STY60NM50
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 500V 60A MAX247
PDF
/
Buying Options
Total Price: USD $20.72
Unit Price: USD $20.724
≥1 USD $20.724
≥10 USD $17.18141
≥100 USD $16.10759
≥500 USD $13.745134
Inventory: 666
Minimum: 1
-
+
Technical Details
Technical
Subcategory FET General Purpose Power
Voltage - Rated DC 500V
Technology MOSFET (Metal Oxide)
Current Rating 60A
Base Part Number STY60N
Pin Count 3
Number of Elements 1
Power Dissipation-Max 560W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 560W
Turn On Delay Time 51 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 50m Ω @ 30A, 10V
Vgs(th) (Max) @ Id 5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 7500pF @ 25V
Current - Continuous Drain (Id) @ 25°C 60A Tc
Gate Charge (Qg) (Max) @ Vgs 266nC @ 10V
Rise Time 58 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 46 ns
Continuous Drain Current (ID) 60A
Threshold Voltage 4V
Gate to Source Voltage (Vgs) 30V
Drain to Source Breakdown Voltage 500V
Pulsed Drain Current-Max (IDM) 240A
Terminal Finish Tin (Sn)
Resistance 50mOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series MDmesh?
Packaging Tube
Operating Temperature 150°C TJ
Dimensions
Height 6.35mm
Length 25.4mm
Width 6.35mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Transistor Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 12 Weeks
