CMDZ5236B TR
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
PDF
/
Inventory: 3979
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Knee Impedance-Max 500Ohm
Voltage Temp Coeff-Max 4.35mV/°C
Reverse Current-Max 3μA
Working Test Current 20mA
Voltage Tol-Max 5%
Reference Voltage 7.5V
Diode Type ZENER DIODE
Power Dissipation-Max 0.25W
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
Operating Temperature (Min) -65°C
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G2
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology ZENER
HTS Code 8541.10.00.50
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1
Pbfree Code icon-pbfree yes
JESD-609 Code e3
Physical
Number of Terminals 2
Diode Element Material SILICON
Surface Mount YES
