STW23N85K5
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 850V 19A TO-247
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 31
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Drain to Source Breakdown Voltage 850V
Gate to Source Voltage (Vgs) 30V
Continuous Drain Current (ID) 19A
Turn-Off Delay Time 55 ns
Fall Time (Typ) 8 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 14ns
Gate Charge (Qg) (Max) @ Vgs 38nC @ 10V
Current - Continuous Drain (Id) @ 25°C 19A Tc
Input Capacitance (Ciss) (Max) @ Vds 1650pF @ 100V
Vgs(th) (Max) @ Id 5V @ 100μA
Rds On (Max) @ Id, Vgs 275m Ω @ 9.5A, 10V
FET Type N-Channel
Turn On Delay Time 22 ns
Element Configuration Single
Power Dissipation-Max 250W Tc
Number of Channels 1
Base Part Number STW23N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SuperMESH5?
Packaging Tube
Operating Temperature 150°C TJ
Physical
Weight 38.000013g
Number of Pins 3
Package / Case TO-247-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 17 Weeks
