STP80PF55
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET P-CH 55V 80A 3-Pin(3+Tab) TO-220 Tube
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1364
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
Drain to Source Breakdown Voltage -55V
Gate to Source Voltage (Vgs) 16V
JEDEC-95 Code TO-220AB
Threshold Voltage -3V
Continuous Drain Current (ID) 80A
Turn-Off Delay Time 165 ns
Fall Time (Typ) 80 ns
Vgs (Max) ±16V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 55V
Rise Time 190ns
Gate Charge (Qg) (Max) @ Vgs 258nC @ 10V
Current - Continuous Drain (Id) @ 25°C 80A Tc
Input Capacitance (Ciss) (Max) @ Vds 5500pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 18m Ω @ 40A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Turn On Delay Time 35 ns
Power Dissipation 300W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 300W Tc
Number of Elements 1
Pin Count 3
Base Part Number STP80P
Current Rating -80A
Technology MOSFET (Metal Oxide)
Voltage - Rated DC -55V
Subcategory Other Transistors
Terminal Finish Tin (Sn)
Resistance 18mOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series STripFET? II
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
